Goods Lift – Counter Weight Type
Jayco Counter Weight Type Goods Lift is a heavy-duty vertical lifting solution designed for the safe, efficient, and reliable transportation of goods between multiple floor levels. The lift operates using a counterweight balancing system, which significantly reduces motor load, minimizes power consumption, and provides smooth, stable, and energy-efficient operation.
Manufactured using premium-quality steel structures, precision guide rails, and advanced electrical control systems, Jayco Counter Weight Goods Lifts are ideal for factories, warehouses, logistics centers, industrial plants, commercial buildings, and distribution facilities. Available in various capacities, platform sizes, and lifting heights, the lifts can be fully customized to suit customer-specific requirements.
Product Specifications
| Parameter | Specification |
|---|---|
| Product Type | Counter Weight Type Goods Lift |
| Lift Type | Electric Goods Lift with Counterweight |
| Operation | Electric Operated |
| Drive System | Wire Rope / Traction Drive with Counterweight |
| Safe Working Load (SWL) | 500 kg to 5,000 kg (0.5 Ton to 5 Ton) |
| Platform Size | Customized as per Requirement |
| Lifting Height | Up to 75 Meters |
| Travel Speed | 6 to 30 Meters/Minute |
| No. of Stops | 2 to 10 Floors (Customized) |
| Door Type | Manual Swing Door / Collapsible Gate / Automatic Sliding Door |
| Guide Structure | MS Guide Rails / Structural Guide Frame |
| Platform Construction | Heavy-Duty Fabricated Steel Platform |
| Control System | Push Button / PLC Based Control Panel |
| Motor | Geared Brake Motor |
| Transmission | Wire Rope & Counterweight System |
| Power Supply | 415V, 3 Phase, 50 Hz AC |
| Motor Insulation | Class F |
| Protection Class | IP55 |
| Surface Finish | Epoxy Primer with Industrial PU Paint |
| Standard Colours | Orange, Light Grey, Yellow & Black (Custom Colours Available) |
| Application | Vertical Material Handling |
Design & Manufacturing Standards
- IS 14665 – Goods Lift Guidelines
- IS 3177 – Electric Overhead Travelling Cranes (Applicable Components)
Standard Features
Structural Features
- Heavy-duty fabricated lift platform
- Robust steel guide structure
- Precision counterweight mechanism
- High-strength wire rope system
- Heavy-duty guide rollers
- Compact and rigid construction
- Long service life
Mechanical Features
- Counterweight balanced operation
- Smooth vertical travel
- Heavy-duty geared drive system
- Precision guide rail assembly
- Reliable traction mechanism
- Low vibration and noise
Electrical Features
- Energy-efficient geared brake motor
- PLC/Relay-based control panel
- Class F insulated motor
- IP55 electrical components
- Floor indication system
- Push-button operation
Safety Features
- Electromagnetic brake
- Overload protection
- Upper & Lower Limit Switches
- Final Limit Switch
- Emergency Stop Button
- Door Interlock System
- Wire Rope Safety Factor as per Standards
- Phase Failure & Phase Reversal Protection
- Over Travel Protection
- Safety Buffers
- Emergency Manual Lowering (Optional)
Optional Features
- Automatic Sliding Doors
- Collapsible Gates
- PLC with Touch Screen HMI
- Variable Frequency Drive (VFD)
- Auto Leveling System
- Automatic Rescue Device (ARD)
- Interlocking Doors
- Digital Floor Display
- Calling Bell & Alarm
- Voice Annunciation
- Cabin Lighting
- Emergency Lighting
- Stainless Steel Cabin
- Outdoor Weatherproof Model
- Flameproof / Explosion Proof Electricals
- Customized Platform Size
- Customized Lift Height
- Customized Paint Shade
Standard Scope of Supply
- Lift Platform
- Counterweight Assembly
- Wire Rope System
- Geared Brake Motor
- Guide Rails & Guide Structure
- Electrical Control Panel
- Landing Gates
- Push Button Operating Panel
- Safety Devices
- Fasteners & Hardware
- Installation Drawings
- Operation & Maintenance Manual
- Routine Test Certificate
- Warranty Certificate
Applications
Jayco Counter Weight Type Goods Lifts are widely used in:
Why Choose Jayco Counter Weight Type Goods Lift
Technical Advantages
- Counterweight system reduces motor load
- Lower power consumption compared to conventional lifts
- Smooth acceleration and deceleration
- Stable vertical movement
- High lifting efficiency
- Heavy-duty guide rail construction
- Reliable braking system
- Easy maintenance
- Suitable for continuous industrial operation
- Designed for multi-floor material handling
Frequently Asked Questions (FAQs)
A Counter Weight Type Goods Lift is an electrically operated lifting system that uses a counterweight to balance the platform, reducing motor effort and ensuring smooth, safe, and energy-efficient transportation of goods between different floors.
Jayco Counter Weight Type Goods Lifts are available in capacities ranging from 500 kg to 5 Ton, with higher capacities available for special industrial applications.
Our goods lifts can be designed for lifting heights of up to 75 meters or more, depending on the building structure and application.
Yes. We offer customized platform sizes, lifting capacities, travel speeds, number of stops, door configurations, control systems, and structural arrangements to suit customer requirements.
They are widely used in manufacturing plants, warehouses, logistics centers, engineering workshops, commercial buildings, pharmaceutical industries, food processing plants, steel plants, and general industrial material handling applications.
Jayco Goods Lifts can be supplied with manual swing doors, collapsible gates, automatic sliding doors, or customized door arrangements based on customer requirements.
Yes. Jayco provides complete installation, testing, commissioning, operator training, and technical support for all goods lift installations.
Yes. We supply genuine spare parts, maintenance services, annual service support, and prompt after-sales assistance to ensure reliable and uninterrupted operation.
Yes. The counterweight system balances the load, reducing motor power requirements, lowering energy consumption, and improving the overall efficiency of the lift.
Jayco Counter Weight Type Goods Lifts are equipped with electromagnetic brakes, overload protection, upper & lower limit switches, final limit switches, door interlocks, emergency stop buttons, phase protection, safety buffers, and high-strength wire rope systems to ensure safe, reliable, and efficient vertical transportation of goods.
