Monorail Hoist
Jayco Monorail Hoist is a compact, efficient, and versatile material handling solution designed for safe and reliable lifting and horizontal movement of loads along a fixed overhead monorail beam. Engineered using premium-quality components and advanced manufacturing technology, our monorail hoists provide smooth lifting, precise load positioning, and effortless travel, making them ideal for production lines, warehouses, engineering workshops, fabrication units, and various industrial applications.
Jayco Monorail Hoists can be supplied with Electric Wire Rope Hoists or Electric Chain Hoists, depending on the lifting capacity, duty cycle, and application requirements. Designed for continuous industrial operation, our monorail hoists are available in a wide range of capacities and lifting heights and can be customized to suit specific customer needs.
Product Specifications
| Parameter | Specification |
|---|---|
| Product Type | Monorail Hoist |
| Hoist Type | Electric Wire Rope Hoist / Electric Chain Hoist |
| Operation | Electric Operated |
| Control | Pendant Push Button Station / Optional Wireless Radio Remote Control |
| Safe Working Load (SWL) | 500 kg to 50,000 kg (0.5 Ton to 50 Ton) |
| Height of Lift | Up to 50 Meters |
| Hoisting Speed | As per Application |
| Travel Speed | 5–20 Meters/Minute |
| Creep Speed | Optional |
| Duty Classification | IS 3938 / IS 3177 / FEM Standards |
| Hoisting Motor | Squirrel Cage Induction Motor with Electromagnetic Brake |
| Travel Motor | Squirrel Cage Induction Geared Motor |
| Motor Insulation | Class F |
| Protection Class | IP55 (Optional IP65) |
| Power Supply | 415V, 3 Phase, 50 Hz AC |
| Power Supply Arrangement | Festoon Cable System |
| Track Compatibility | ISMB / ISWB / Custom Monorail Beam |
| Standard Colours | Orange, Light Grey, Yellow & Black (Custom Colours Available) |
| Application | Industrial Material Handling & Lifting |
Standard Features
- Compact and space-saving design
- Heavy-duty fabricated trolley
- Smooth lifting and horizontal travel
- Precision load positioning
- Suitable for straight or curved monorail tracks
- Low headroom design available
- Robust geared travel mechanism
- Fail-safe electromagnetic braking system
- Quiet and vibration-free operation
- Energy-efficient motors
- Corrosion-resistant industrial paint finish
- Easy installation and maintenance
- Long service life
- Suitable for continuous industrial duty
- Manufactured using premium-quality components
- Available in customized specifications
Optional Features
- Low Headroom Design
- Anti-Drop Device
- Soft Start through VFD
- Curved Track Arrangement
- Limit Switches
- Radio Remote Control
- Flameproof / Explosion Proof Version
- Stainless Steel Construction (Special Applications)
- Customized Track Length
- Load Indicator
- Key Features
- Compact and space-saving design
- Smooth lifting and monorail travel
- Heavy-duty wire rope construction
- High-strength forged hook with safety latch
- Reliable electromagnetic braking system
- Low maintenance and long service life
- Quiet and vibration-free operation
- Energy-efficient performance
- Easy installation and operation
- Suitable for continuous industrial duty
- Corrosion-resistant industrial finish
- Manufactured as per IS 3938 standards
- Custom-built solutions available
Applications
Jayco Monorail Hoists are widely used in:
Why Choose Jayco Monorail Hoist?
Frequently Asked Questions (FAQs)
A Monorail Hoist is a lifting system in which an electric hoist travels along a fixed overhead beam or monorail track, enabling safe lifting and horizontal movement of materials within a defined path.
Jayco Monorail Hoists are available in capacities ranging from 500 kg (0.5 Ton) to 50 Ton. Higher capacities can be supplied on request.
Depending on the application, Jayco Monorail Systems can be equipped with either an Electric Wire Rope Hoist or an Electric Chain Hoist.
Yes. We offer customized lifting capacities, lifting heights, beam sizes, track layouts, travel speeds, control systems, and power supply arrangements to suit customer requirements.
Monorail Hoists are widely used in manufacturing plants, warehouses, engineering workshops, fabrication units, assembly lines, automobile industries, steel plants, chemical plants, pharmaceutical industries, and material handling systems.
The hoist can be operated using a Pendant Push Button Station or an optional Wireless Radio Remote Control.
Yes. Jayco provides installation, testing, commissioning, operator guidance, and technical support whenever required.
Yes. We provide genuine spare parts and prompt after-sales service to ensure maximum uptime and reliable operation.
Yes. Depending on the application, Jayco can design and supply Monorail Hoists suitable for both straight and curved monorail track systems.
Jayco Monorail Hoists are equipped with a fail-safe electromagnetic brake, overload protection options, limit switches, robust trolley construction, and reliable electrical controls to ensure safe and efficient lifting operations.
